Where to buy
3 vendorssorted by per-unit pricelast checked 1d ago
Prices from partner vendors. Some are affiliate links — we may earn a commission at no extra cost to you. Learn more.
45-pack1 offer
from $0.66 / unit- Keychron— Banana (Two-Stage Spring), 3 PinChecked 26h agoOut of stockNotify$29.99Check at Keychron$0.66 / unit
110-pack2 offers
from $0.28 / unit- Gateron— Red, 5 PinUpdated 18h agoOut of stockNotify$31.00Check at Gateron$0.28 / unit
- Amazon— BananaBestUpdated 19h agoIn stock$31.99Buy at Amazon$0.29 / unit
Specifications
- Type
- Linear
- Actuation force
- 55 gf
- Bottom-out force
- 65 gf
- Pre-travel
- 2 mm
- Total travel
- 4 mm
- Spring
- two-stage
- Pin count
- 5-pin
- LED slot
- Yes
- Operating life
- 50,000,000 cycles
- Factory lubed
- Yes
- Stem
- MX (Cherry-compatible)
Not sure about a term? Hover the dotted-underlined values for a quick definition, or read Switches 101.
Smooth, muted "thock" — factory lube damps spring ping and stem friction.
We're collecting community-contributed sound tests. Meanwhile, Switches 101 explains how switch type, lube and housing material shape sound.
Full force-curve plots aren't ingested yet. Below is the pair we track on every switch — useful for a quick weight sanity check.
Looking for full graphs? Switches 101 → force curves explains how to read them and which weight range suits your typing style.
No community review summary has been published for this product yet.
We summarize reviews from Amazon, Reddit, ThereminGoat, Geekhack and YouTube once enough coverage is collected. In the meantime, our buying guides cover which specs to look for.
Compatibility
- Fits these sockets
Gateron Hotswap, Kailh Hotswap
Drop-in compatible hot-swap sockets.
- PCB requirement
5-pin PCB socket
Also fits 3-pin sockets after trimming the plastic legs.
- Keycap stem
MX (Cherry-compatible) stem
Works with any keycap set cut for this stem type.
Specs from community sources (Gateron product page descriptions are minimal); needs verifier refresh. Jupiter — Banana/etc. variants
Side-by-side comparison
| Spec | |||||
|---|---|---|---|---|---|
| Type | Linear | Linear | Linear | Linear | Linear |
| Bottom-out | 65 gf | 56 gf | 40 gf | 48 gf | — |
| Factory lubed | Yes | — | — | — | — |
| Score | — | — | — | — | — |
| From | $0.29 | — | — | — | — |
Need more detail? Open full comparison →
